Oil Resistant Lubricator
Oil Resistant Lubricator
Oil Resistant Lubricator
YAP
| 1. With temperature protection device for long term operation. |
| 2. Three operation modes as, |
| a. Lubrication ：the lubricator runs via lubrication time after power-on. |
| b. Intermittence： The lubricator runs via intermittent time after power-on. |
| c. Memory：The lubricator runs via previous set after power-on. |
| 3. Lubrication and intermittent time can be adjusted. |
| 4. The flaot switch alarms and output signal when the oil level is low. |
| 5. The function of fixed pressure for the pressure relief valve can prolong the system life |
| 6. Lubrication time (second/minute) and intermittent time (second/minute/hour/cycle) are adjustable. |
| 7. The indicator on the panel can display the operation of the lubricator. |
| 8. The intermittent period can be adjusted via the machine's action cycles. |
| 9. "RES" key can force the lubricator to function. |
| 10. Cooperorate with distributors of resistance lubricator and proportion devices. |
| Model | YAP |
| Voltage (Single Phase) | 110V or 220V |
| Consumption Power (W) | 164 |
| Output Power (W) | 90 |
| Capacity of Terminal Output | DC/AC 250V 3A |
| Lubrication Time(second/minute) | 1-999 |
| Intermittent Time(second/minute/hour/cycle) | 1-999 |
| Output Bore | Ø4 or Ø6 |
| Max. Output Pressure Mpa (kgf/cm2) | 3(30) |
| Output Volume (cc/ min) | 600 |
| Float Switch | O |
| Pressure Release Devices | X (Option) |
| Pressure Switch (kgf/cm2) | X (Option) |
| Pressure Gauge | O |
| Alarm Beeper | O |
| Tank Capacity (L) | 8 |
| Weight (kg) | 10 |
Note： Because of continuous improvements, above specifications are subject to change without prior notice.
