Oil Resistant Lubricator
Oil Resistant Lubricator
Oil Resistant Lubricator
YMT
| 1. Compact size for installation. |
| 2. Easy operation. |
| 3. Include check valves to prevent the reverse flow. |
| 4. The system is recommended to applied to easier machinery system with the lubrication of lower requirement level. |
| 5. Oil viscosity (40°C)： 20~150cSt. |
| Model | YML-8 |
| Output Volume (cc/cy) | 8 |
| Max. output Pressure Mpa (kg/cm2) | 1.5 (15) |
| Tank Capacity (cc) | 600 |
| Effective Capacity (cc) | 450 |
| Output Bore | Ø4 or Ø6 |
| Direction of Bore | Left or Right |
| Weight (kg) | 1.4 |
Note： Because of continuous improvements, above specifications are subject to change without prior notice.
