Oil Resistant Lubricator
Oil Resistant Lubricator
Oil Resistant Lubricator
YET-N-4L
| 1. Two operation modes as, |
| a. Lubrication： The lubricator runs via lubrication time after power-on. |
| b. Intermittence：The lubricator runs via intermittent time after power-on. |
| 2. Intermittent time is adjustable. |
| 3. The float switch output signal when the oil level is low(For YET-N, the beeper alarms when the oil level is low). |
| 4. The over temperature/load protector is attached to protect the motor. |
| 5. The function of fixed pressure for the pressure relief valve can prolong the system life |
| 6. The indicator on the panel can display the operation of the lubricator. |
| 7. The pressure is optional via customer's demand. |
| 8. Output Pressure can reach 7 kgf/cm2 to make sure each port with enough output volume. |
| 9. "Feed" key can force the lubricator to function. |
| Model | YET-N | ||
| Voltage (Single Phase) | 110V or 220V | ||
| Consumption Power (W) | 80 | ||
| Capacity of Terminal Output (A) | 3 | ||
| Lubrication Time (second) | － | ||
| Intermittent Time (minute) | 0-60 | ||
| Output Bore | Ø4 or Ø6 | ||
| Max. Output Pressure Mpa (kgf/cm2) | 0.7(7) | ||
| Output Volume (cc/cycle) | 6 (Standard) 15 (Option) | ||
| Float Switch | O | ||
| Pressure Gauge | X | O | O |
| Alarm Beeper | O | ||
| Tank Capacity (L) | 2 | 3 | 4 (Aluminum Tank) |
| Weight (kg) | 2.6 | 2.9 | 3.6 |
Note： Because of continuous improvements, above specifications are subject to change without prior notice.
