1. Two operation modes as, |
a. Lubrication: The lubricator runs via lubrication time after power-on. |
b. Intermittence:The lubricator runs via intermittent time after power-on. |
2. Intermittent time is adjustable. |
3. The over temperature/load protector is attached to protect the motor. |
4. The function of fixed pressure for the pressure relief valve can prolong the system life |
5. The indicator on the panel can display the operation of the lubricator. |
6. The pressure is optional via customer's demand. |
7. Output Pressure can reach 7 kgf/cm2 to make sure each port with enough output volume. |
8. "Feed" key can force the lubricator to function. |
Model | YET-E | ||
Voltage (Single Phase) | 110V or 220V | ||
Consumption Power (W) | 80 | ||
Capacity of Terminal Output (A) | 3 | ||
Lubrication Time (second) | - | ||
Intermittent Time (minute) | 0-60 | ||
Output Bore | Ø4 or Ø6 | ||
Max. Output Pressure Mpa (kgf/cm2) | 0.7(7) | ||
Output Volume (cc/cycle) | 6 (Standard) 15 (Option) | ||
Float Switch | O | ||
Pressure Gauge | X | O | O |
Alarm Beeper | X | ||
Tank Capacity (L) | 2 | 3 | 4 (Aluminum Tank) |
Weight (kg) | 2.6 | 2.9 | 3.6 |
Note: Because of continuous improvements, above specifications are subject to change without prior notice.
