Spray Mist Lubricator
Spray Mist Lubricator
Spray Mist Lubricator
YSM-C
1. The float switch outputs signal when the iol level is low.
2. The indicator on the panel can display the operation of the lubricator.
3. The cooling, lubrication, and cleaning during machining can be completed at the same time.
4. The oil volume in air can be adjusted.
5. High cooling efficiency.
6. YSM-C is suitable for high-speed and high-precision machining.
| Type | Lubrication Time(0.1sec) | Intermittent Time (sec./mon./cy) | Voltage (Single Phase) | Capacity of Terminal Output (A) | Output Bore |
| YSM-C | Cooperate with PLC control system | Cooperate with PLC control system | 110V/220V | 3 (Float Switch) | Ø6 |
| Type | Air Pressure Range Mpa (kgf/cm2) | Spray Particle Size | Alarm Beeper | Float Switch | Tank Capacity(L) | Weight (kg) |
| YSM-C | 0.3-0.5 (3-5) | 4-10um | X | O (NC) | 4 | 10.1 |
