Spray Mist Lubricator

Spray Mist Lubricator

Spray Mist Lubricator

YSM-A

1. Three operation modes as,
     a. Lubrication: The lubricator runs via lubrication time after power-on.
     b. Intermittence:The lubricator runs via intermittent time after power-on.
     c. Memory:The lubricator runs via the previous set aftwr power-on.
2. Lubrication and intermittent time can be adjusted. The minimum unit of lubrication is 0.1 second.
3. The float switch alarms and outputs signal when the oil level is low.
4. The indicator on the panel can display the operation of the lubricator.
5. The intermittent period can be adjusted via the machine action cycles.
6. The cooling, lubrication, and cleaning during machining can be completed at the same time.
7. The oil volume in air can be adjusted.
8. High cooling efficiency.
9. YSM-A is suitable for high-speed and high-precision machining.
10. The required air capacity is 31L/min for maintaining the working pressue of 0.3 Mpa (3 kgf/cm2)
TypeLubrication Time(0.1sec)Intermittent Time (sec./mon./cy)Voltage (Single Phase)Capacity of Terminal OutputOutput Bore
YSM-A1-9991-999110V/220VDC/AC 250V 3AØ6



TypeAir Pressure Range Mpa (kgf/cm2)Spray Particle SizeAlarm BeeperFloat SwitchTank Capacity(L)Weight (kg)
YSM-A0.3-0.5 (3-5)4-10umOO410.1
