1. Two operation modes as, |
a. Lubrication: The lubricator runs via lubrication time after power-on. |
b. Intermittence:The lubricator runs via intermittent time after power-on. |
2. Lubrication and intermittent time can be adjusted. |
3. The indicator on the panel can display the operation of the lubricator. |
4. The function of fixed pressure for the pressure relief valve can prolong the system life |
5. "FEED" key can force the lubricator to function. |
Model | YGL-R | ||
Voltage | 110V or 220V (Single Phase) | ||
Consumption Power (W) | 56 | ||
Output Power (W) | 25 | ||
Capacity of Terminal Output | DC/AC 250V 3A | ||
Lubrication Time (second) | 2-180 | ||
Intermittent Time (minute) | 0.5-180 | ||
Output Bore | PT1/4 | ||
Max. Output Pressure Mpa (kgf/cm2) | 8-10(80-100) | ||
Output Volume (c.c./ min) | Above 13 | ||
Pressure Gauge | O | ||
Cup Capacity (cc) | 800 | 1200 | 2000 |
Weight (kg) | 3.7 | 4.6 | 5 |
Note: Because of continuous improvements, above specifications are subject to change without prior notice.
