1. The indicator on the panel can display the operation of the lubricator.
2. Fixed pressure of the pressure relif valve protects the pump and the pipe.
3. "FEED" key can force the lubricator to function.
4. The motor is of long-time operation.
Model | YGL-C | ||
Voltage (Single Phase) | 110V or 220V | ||
Consumption Power (W) | 56 | ||
Power (W) | 25 | ||
Lubrication Time | Cooperate with PLC control system | ||
Intermittent Time | Cooperate with PLC control system | ||
Output Bore | PT1/4 | ||
Max. Output Pressure Mpa (kgf/cm2) | 8-10(80-100) | ||
Output Volume (c.c./ min) | Above 13 | ||
Pressure Gauge | O | ||
Tank Capacity (cc) | 800 | 1200 | 2000 |
Weight (kg) | 3.6 | 4.4 | 4.9 |
