1. Two operation modes as, |
a. Lubrication: The lubricator runs via lubrication time after power-on. |
b. Intermittence: The lubricator runs via intermittent time after power-on. |
2. Lubrication time and intermittent time are adjustable. |
3. The float switch alarms and output signal when the oil level is low. |
4. The over temperature/load protector is attached to protect the motor. |
5. The function of fixed pressure for the pressure relief valve can prolong the system life |
6. The indicator on the panel can display the operation of the lubricator. |
7. “Feed” key can force the lubricator to function. |
Model | YET-R2 |
Voltage (Single Phase) | 110V or 220V |
Consumption Power (W) | 100 |
Capacity of Terminal Output (A) | 3 |
Lubrication time (second) | 1-180 |
Intermittent Time (minute) | 1-180 |
Output Bore | Ø4 or Ø6 |
Max. Output Pressure Mpa (kgf/cm2) | 1.5 (15) |
Output Volume (cc/mm) | 150 |
Float Switch | O |
Pressure Release device | O |
Pressure Gauge | O |
Alarm Beeper | O |
Tank Capacity (L) | 2 / 3 / 4(Metal Tank) |
Weight (kg) | 2.6 / 2.9 / 3.6 |
